1 LEDGlow Lighting, LLC • LEDGlow.com Tech Support 856-768-5700 Ext. 2 • TechSupport@LEDGlow.com ® INSTALLATION GUIDE WARNING: THIS PRODUCT IS DESIGNED FOR OFF ROAD USE ONLY. PLEASE CHECK YOUR LOCAL AND STATE LAWS FOR THE PROPER USE OF THIS PRODUCT. Every state has different policies and procedures in place regarding aftermarket LED lighting accessories. LEDGlow is not responsible for any fines that you may receive while using this lighting kit. Note: We recommend using a licensed professional to install this lighting kit. The improper installation of this kit will void all warranties. We recommended installing each lighting strip using Adhesion Promoter, which allows for a much stronger bond between the adhesive tape of the light strip and the cleaned mounting surface of your Can Am Spyder. PLEASE READ THE FOLLOWING INSTRUCTIONS THOROUGHLY BEFORE INSTALLING AND OPERATING THIS LED SPYDER KIT. SPYDER LIGHTING KIT INCLUDES: • Bluetooth Control Box • (2) 2” Strips • Adhesion Promoter • (2) Wireless Remotes • (2) 4” Strips • Zip Ties • (2) 3pc Power Harness • (6) 6” Strips • (6) Zip Tie Mounts • (2) 6pc Add-On Harnesses • (20) 10” Strips • (2) Crimp-on Ring Terminals • (4) 4pc Add-On Harness • (4) 18” Strips • T-tap Connector • (2) 2pc Add-On Harness • (4) 24” Strips • Crimp on male spade terminal • (2) 3’ Extension • Alcohol Pads • Double-Sided Tape for Control Box 1. Upon receiving your new Spyder lighting kit, we ask that you first test the kit to ensure it is functioning correctly. Plug the male connections from the strips and control box into the female connections of the harnesses. Connect the red power wire to the positive terminal of the battery and the black ground wire to the negative terminal of the battery. Once the wires are temporarily secure, power the kit to ensure full functionality before installing it. (please refer to the pairing instructions starting on page 4) If everything appears to be working correctly, turn the kit off and disconnect the power and ground wires from the battery to prepare for installation. 2. Remove any plastic panels that will be in your way starting with the air cleaner and side panels, most of which are held on with T30 Torx Head bolts and push pin clips. Note: The strips can be mounted in any area that isn’t hot or near moving parts. However, we recommend installing the light strips in a manner that has the left side and the right side on separate zones. This will give a different effect from the dual zone feature that is integrated in the Bluetooth Control Box. 3. Recommended mounting locations: • (2) 24” under the swing arm one on each side • (1) 24” on the right frame rail next to the air box • (2) 18” strips under the front nose • (1) 18” on the right side on the air box lid • (2) 18” on left side frame rail above the exhaust • (4) 10” strips under the control arms on both sides • (2) 10” strips under the lower plastic • (2) 10” both on inside of swing arm • (3) 10” strips on air intake scoops on both sides • (1) 6” behind the shifter • (1) 6” behind the brake pedal • (1) 6” strip above the battery on the left side • (1) 6” under seat handle on the right side • (1) 6” strip on headlight surround on both sides • (1) 4” strip arounnd the horn on the left side • (1) 4” strip under the right headlight • (1) 2” strip on the coil mount on the left side • (1) 2” strip infront of the radiator on the right side 4. Be sure to clean all of the mounting areas with alcohol prep pads and apply adhesion promoter to the cleaned areas. 5. Attach the strips by pressing firmly onto the desired mounting locations. Secure with zip ties when possible. 6. Starting with (2) 18” strips, attach under the front nose: one on each side while running the wires up to the headlight areas. 7. Mount (4) 10” strips on the left side upper and lower control arms. 8. Mount a 4” strip on the horn located on the left side to illuminate the area behind the front vent. 9. Mount (4) 10” strips on the right upper and lower control arms. 10. Mount a 4” strip under the right side headlamp to illuminate the front vent. 11. Mount a 2” strip in front of the radiator on the right side 12. A 24” strip gets mounted under the right side frame rail above the radiator.
